D71X-10P sanitary butt-clamp butterfly valve is a kind of valve designed for sanitary process fluid control. The valve body, valve stem and other key components are mostly made of 304 stainless steel, with good corrosion resistance and high temperature resistance. The sealing material is made of food-grade silicone, which is non-toxic, odorless and meets the sanitary requirements. It is characterized by compact structure, easy cleaning, flexible operation and good sealing performance. It is widely used in food, beverage, pharmaceutical, cosmetic and other industries that require high hygiene standards.
Product Parameters
Product Model | D71X-10P |
Valve body material | 304 Stainless Steel |
Valve plate material | 304 Stainless Steel |
Rubber lining material | silicone rubber |
Nominal pressure | ≤1.0Mpa |
Applicable medium | Water, Gas, Oil, etc. |
Applicable temperature | ≤100°C |
Product Size Reference
Nominal Diameter | I | B | E | d | F |
| D |
DN25 | 32 | 28 | 25.5 | 42 | 60 | 131 | 111 |
DN32 | 38.5 | 36 | 30.5 | 54 | 73 | 157 | 130 |
DN40 | 41 | 38 | 37.5 | 62 | 80 | 164 | 130 |
DN50 | 44 | 41 | 48 | 72 | 94 | 190 | 148 |
DN65 | 46.5 | 44 | 64 | 87 | 108 | 204 | 148 |
DN80 | 49 | 45 | 78 | 96 | 126 | 223 | 148 |
DN100 | 53.5 | 50 | 96 | 119 | 158 | 263 | 148 |
DN125 | 59 | 55 | 121 | 145 | 173 | 288 | 218.5 |
DN150 | 61 | 55 | 148 | 182 | 208 | 311 | 248 |
